Map

The Map module embeds an interactive Google Map with custom pin locations directly into your Divi 5 layout.

Quick Reference

What it does: Embeds an interactive Google Map with custom pins, info windows, and map controls. When to use it: Contact pages, multi-location directories, event venue maps Key settings: Center Map Address, Zoom Level, Add New Pin, Controls, Map Height Block identifier: divi/map ET Docs: Official documentation

When to Use This Module

• Showing a business location or office address on a contact page
• Displaying multiple locations with individual pins and info windows
• Embedding an interactive map that visitors can zoom and pan

When NOT to Use This Module

• Needing a full-browser-width map display → use Fullwidth Map
• Displaying a static location image rather than an interactive map → use Image

Overview

The Map module lets you display a fully interactive Google Map on any page built with Divi 5. You can define a center address, set the zoom level, and place multiple custom pins at specific locations, each with its own title and description that appear in an info window when clicked. This makes the module an effective way to show your business location, office addresses, store branches, event venues, or any set of geographic points of interest.

Google Maps integration in Divi 5 requires a valid Google Maps API key, which you configure in the Divi Theme Options panel. Once the API key is set, every Map module on your site will render a live, draggable, zoomable map that visitors can interact with. The module supports standard Google Maps controls including zoom buttons, street view access, and map type switching between roadmap, satellite, terrain, and hybrid views.

The Design tab provides controls for the map container styling, while the map pins themselves can be individually configured with titles and descriptions. For locations that require a larger map display, consider the Fullwidth Map module, which spans the entire browser width. The standard Map module fits within a column and can be placed alongside other modules in multi-column rows, making it suitable for contact pages, location directories, and about sections.

For additional reference, see the official Elegant Themes documentation.

View A Live Demo Of This Module

The Map module displaying an interactive Google Map with a location pin.

Use Cases

1. Business Contact Page — Display your office or storefront location on a contact page alongside your address, phone number, and contact form. Add a pin with your business name and a brief description so visitors can identify the location at a glance.

2. Multi-Location Directory — Add multiple pins to a single map to show all of your branches, franchises, or service areas. Each pin can have a unique title and description, helping visitors find the nearest location and view relevant details in the info window.

3. Event Venue Map — Embed a map on an event page to show attendees exactly where the venue is located. Set the zoom level to show nearby landmarks, parking areas, and transit options so visitors can plan their trip.

How to Add the Map Module

1. Open the Visual Builder — Navigate to the page where you want the map and activate the Divi 5 Visual Builder. Click the plus icon in the section and row where the map should appear.

2. Select the Map Module — Search for "Map" in the module picker or browse the module list. Click to insert it into your chosen column.

3. Configure the Map — Enter a center address and adjust the zoom level in the Content tab. Add one or more pins by clicking the "Add New Pin" button, then enter the address, title, and description for each pin. Adjust the map height and styling in the Design tab.

Settings & Options

Content Tab

The Content tab controls the map configuration, pin locations, and general module settings.

Setting	Type	Description
Add New Pin	button	Opens the pin configuration panel where you add individual map markers. Each pin has its own title, content description, and address fields. The address is geocoded to place the pin at the correct coordinates on the map.
Map	group	Contains the core map configuration settings — the center map address (the location the map is initially centered on), the zoom level (which controls how close or far the initial view is), and the map type.
Link	group	Configure a link URL applied to the module wrapper element. Includes link target settings for same window or new tab behavior.
Background	group	Apply a background color, gradient, or image behind the module container. This is visible if the map container has padding or if the map fails to load.
Loop	toggle	When used inside a dynamic layout such as a Theme Builder template, this controls whether the module repeats for each item in a post loop.
Order	select	Determines the display order of the module relative to sibling modules within the same container.
Meta	group	Contains the admin label field for assigning a custom name to this module instance in the Visual Builder layers panel.

Design Tab

The Design tab provides visual customization for the map container and the controls displayed on the map.

Module-specific settings:

Setting	Type	Description
Controls	group	Toggle the visibility of Google Maps UI controls such as the zoom buttons, map type selector, street view pegman, and fullscreen button. Disabling controls creates a cleaner presentation but limits interactivity.
Map	group	Configure the map container appearance including the map height, which determines how tall the embedded map is in pixels. Also includes options for the draggable state and mouse wheel zoom behavior.

Shared design options — see Options Groups for detailed documentation:

Options Group	Description
Sizing	Width, max-width, height, min-height
Spacing	Margin and padding per side, responsive breakpoints
Border	Width, color, style, border radius
Box Shadow	Color, offsets, blur radius, spread
Filters	Brightness, contrast, saturation, hue, blur, invert, blend mode
Transform	Scale, translate, rotate, skew, transform origin
Animation	Entrance animation style, duration, delay, intensity

Advanced Tab

The Advanced tab provides HTML attributes, custom CSS, conditional display logic, and scroll-based effects.

Shared advanced options — see Options Groups for detailed documentation:

Options Group	Description
Attributes	CSS ID, classes, custom HTML attributes
CSS	Custom CSS per element target (map container, pin info windows, module wrapper)
HTML	Custom HTML attributes for module wrapper (data attributes, ARIA labels)
Conditions	Display rules (user role, page type, date, logic)
Interactions	Hover, click, or scroll-triggered interactions
Visibility	Device visibility toggles
Transitions	Hover transition timing
Position	CSS position and offsets
Scroll Effects	Scroll-driven animation effects

Code Examples

Custom CSS — Rounded Map Container

/* Apply rounded corners and shadow to the map */
.et_pb_map_container {
    border-radius: 12px;
    overflow: hidden;
    box-shadow: 0 4px 16px rgba(0, 0, 0, 0.1);
}

Custom CSS — Grayscale Map Style

/* Desaturate the map for a muted, modern look */
.et_pb_map_container iframe,
.et_pb_map_container .gm-style {
    filter: grayscale(100%);
    transition: filter 0.3s ease;
}

/* Restore color on hover */
.et_pb_map_container:hover iframe,
.et_pb_map_container:hover .gm-style {
    filter: grayscale(0%);
}

Custom CSS — Custom Map Height Per Device

/* Adjust map height for different screen sizes */
.et_pb_map_container {
    height: 450px;
}

@media (max-width: 980px) {
    .et_pb_map_container {
        height: 350px;
    }
}

@media (max-width: 767px) {
    .et_pb_map_container {
        height: 250px;
    }
}

PHP — Filter Map Module Output

/* Add a caption below every Map module */
add_filter('et_module_shortcode_output', function($output, $render_slug) {
    if ('et_pb_map' !== $render_slug) {
        return $output;
    }

    $caption = '<p class="map-caption">Click the map to explore. Use pins for location details.</p>';
    return $output . $caption;
}, 10, 2);

JavaScript — Custom Map Styling via Google Maps API

/* Apply a custom map style after the map loads */
document.addEventListener('DOMContentLoaded', function() {
    const checkMap = setInterval(function() {
        const maps = document.querySelectorAll('.et_pb_map');
        if (maps.length > 0) {
            clearInterval(checkMap);
            // Access the Google Map instance through Divi's API
            // to apply custom JSON styling for colors, labels, etc.
        }
    }, 500);
});

Common Patterns

1. Contact Page with Map and Form

Place the Map module in a two-column row alongside a contact form or a column containing your address, phone number, and email. Set a single pin at your business location with your company name as the title and your full address in the description. This gives visitors both a visual reference and a way to reach you.

2. Multi-Location Store Finder

Add multiple pins to the map, one for each branch or service location. Give each pin a descriptive title (such as the branch name or city) and include the address, hours, or phone number in the pin description. Set the zoom level wide enough to show all locations simultaneously, and consider placing the map in a fullwidth section for maximum visibility.

3. Styled Minimal Map

Apply the grayscale CSS filter to the map for a muted, monochromatic appearance that blends with modern, minimalist page designs. Use the hover color-restore technique so the map comes to life when visitors interact with it. Round the container corners with border radius and add a subtle box shadow to frame the map as a design element rather than a utilitarian embed.

AI Interaction Notes

Create vs. Modify

Modifying existing module content via REST API (wp.apiFetch PATCH) updates title, body text, and settings attributes. Creating new modules via REST API produces content that renders on the front end but may not appear in the Visual Builder layer view. Use browser automation for reliable module creation. See REST API Content Playbook.

Block identifier: divi/map — Needs verification on current build

Operation	Method	Status	Notes
Read content	Parse post_content block JSON	Observed	Use brace-depth parser — see Content Encoding
Modify existing	wp.apiFetch PATCH on post endpoint	Observed	Update block attributes in post_content
Create new	Browser automation (Playwright)	Observed	REST creation may break VB visibility
Batch modify	Sequential REST requests	Needs Testing	See REST API Content Playbook

Key content attributes — JSON paths need verification:

Attribute	JSON Path	Notes
Address	attrs.address	Center map address for geocoding
Zoom Level	attrs.zoom_level	Initial map zoom (1-22)
Mouse Wheel	attrs.mouse_wheel	Enable/disable scroll zoom

Module Selection Guidance

For maps in content columns use Map; for edge-to-edge maps use Fullwidth Map.

Saving Your Work

After configuring the Map module and adding your pins, click the green checkmark button at the bottom of the settings panel to apply your changes. Save the page using the save button in the Visual Builder toolbar or press Ctrl+S (Cmd+S on Mac). Preview the page on the front end to verify the map loads correctly and all pins appear at the expected locations.

Version Notes

Divi 5 Only

This page documents Divi 5 behavior exclusively.

Troubleshooting

Map Not Displaying

If the Map module shows a blank area or an error message instead of the map:

• Verify that a valid Google Maps API key is entered in Divi Theme Options under the Integration tab. The API key must have the Maps JavaScript API and Geocoding API enabled in the Google Cloud Console.
• Check the browser console for API error messages such as "ApiNotActivatedMapError" or "InvalidKeyMapError" — these indicate configuration issues with the API key.
• Ensure the Google Cloud project associated with the API key has billing enabled, as Google requires an active billing account for Maps API usage.
• Clear your browser cache and any page caching plugins to load the latest version of the page.

Pins Not Appearing at Correct Locations

If map pins are misplaced or not showing at all:

• Double-check the address entered for each pin. The Geocoding API converts addresses to coordinates, so an incomplete or ambiguous address may resolve to an unexpected location.
• Try entering the full address including street number, city, state/province, and country for the most accurate pin placement.
• If a pin does not appear, open the pin settings and verify that the address field is not empty and that the pin has not been accidentally deleted.

Map Loads Slowly or Causes Layout Shift

If the map takes a long time to appear or pushes content around as it loads:

• Set an explicit height on the map container using the Design tab sizing controls. This reserves space in the layout before the map loads, preventing content shift.
• Consider lazy-loading the map by placing it lower on the page so it only initializes when the user scrolls near it.
• If the page has multiple maps, each one makes additional API calls — consolidate locations into a single map with multiple pins where possible.
