Fullwidth Menu

The Fullwidth Menu module displays a WordPress navigation menu that spans the entire width of a fullwidth section, with optional logo, search, and cart icons.

Quick Reference

What it does: Displays a full-width horizontal navigation bar from any WordPress menu with optional logo, search, and cart icons. When to use it: Custom Theme Builder headers, secondary page navigation, footer navigation bars Key settings: Menu select, Logo image, Shopping Cart toggle, Search Icon toggle, Layout style, Dropdown styling Block identifier: divi/fullwidth-menu ET Docs: Official documentation

When to Use This Module

• Building a custom header in the Theme Builder with logo, menu, and utility icons
• Adding a secondary navigation bar for long-form or documentation pages
• Creating a full-width footer navigation with legal and utility links

When NOT to Use This Module

• For menus within standard content sections → use Menu
• For widget-based sidebar navigation → use Sidebar
• For a single row of links without dropdowns → consider Social Media Follow or manual links

Overview

The Fullwidth Menu module places a complete navigation menu inside a fullwidth section, stretching the menu bar from edge to edge. It pulls from any WordPress menu you have created under Appearance > Menus, and presents the links in a horizontal bar with dropdown support for nested menu items. The module also supports an optional logo image, a search icon, and a WooCommerce shopping cart icon.

This module is the fullwidth counterpart of the standard Menu module. While both share the same settings and functionality, the Fullwidth Menu is designed exclusively for fullwidth sections and takes advantage of the extra horizontal space. It is particularly useful for building custom header areas within the Divi 5 Theme Builder, creating secondary navigation bars on long-form pages, or adding persistent site-wide navigation that is visually distinct from the primary theme header.

On smaller screens, the horizontal menu items automatically collapse into a mobile-friendly hamburger menu. The dropdown menu behavior, icon styling, and mobile breakpoint are all configurable through the module's settings, giving you full control over the navigation experience across all devices.

For additional reference, see the official Elegant Themes documentation for the Menu module.

View A Live Demo Of This Module

The Fullwidth Menu module displaying a horizontal navigation bar with logo and menu links.

Use Cases

1. Custom Theme Builder Header — Use the Fullwidth Menu module in a Divi 5 Theme Builder header template to create a branded navigation bar with your logo, primary menu links, a search icon, and a WooCommerce cart icon, all spanning the full browser width.

2. Secondary Page Navigation — Add a Fullwidth Menu below the main header on long-form pages like documentation or resource centers, providing a persistent second-level navigation that links to page sections or related pages within a category.

3. Footer Navigation Bar — Place a Fullwidth Menu in a fullwidth section near the bottom of the page to present a streamlined set of important links (privacy policy, terms, sitemap, contact) in a compact horizontal bar that complements the main footer area.

How to Add the Fullwidth Menu Module

1. Open the Visual Builder and ensure the page has a fullwidth section. If needed, click the blue + icon and select Fullwidth as the section type.

2. Click the gray + icon inside the fullwidth section to open the module picker.

3. Search for "Fullwidth Menu" or browse the Fullwidth Modules category, then click to insert it into the section.

Settings & Options

The Fullwidth Menu module settings are organized across three tabs: Content, Design, and Advanced.

Content Tab

The Content tab controls which menu is displayed, the logo image, optional utility icons, and background styling.

Setting	Type	Description
Content	select	Choose which WordPress menu to display. Lists all menus created under Appearance > Menus. If no menus exist, you will need to create one in the WordPress admin first.
Logo	image upload	Upload or select a logo image to display alongside the menu. The logo appears on the left side of the menu bar (or centered, depending on layout). Useful for branding in secondary navigation bars or Theme Builder headers.
Elements	toggle checkboxes	Control visibility of optional utility icons: Shopping Cart (requires WooCommerce to be active) and Search Icon (adds a click-to-expand search field in the menu bar).
Link	url	Make the entire module clickable, redirecting users to another page, section, or external URL.
Background	background controls	Set a background color, gradient, image, or video behind the menu module. Useful for creating a visually distinct navigation bar that stands out from the page content.
Loop	toggle	Enable the Loop Builder to dynamically generate menu content from posts or other data sources.
Order	select	Control the display order of the module when placed inside a Flexbox or CSS Grid layout container.
Meta	admin label	Set a custom label to identify the module in the Visual Builder's layer panel. Includes a toggle to force visibility in the builder.

Design Tab

The Design tab controls the menu layout, typography, dropdown styling, icon appearance, and all visual presentation options.

Module-specific settings:

Setting	Type	Description
Layout	select	Choose the menu bar style: Left Aligned (logo left, links right), Centered (links centered below or beside logo), or Inline Centered Logo (logo centered between two groups of links). Also set the dropdown menu direction (downward or upward).
Menu Text	text styling	Configure the typography for top-level menu items: font family, weight, size, color, letter spacing, line height, and text transform. Supports separate hover state colors.
Dropdown Menu	color/style controls	Customize the dropdown sub-menu appearance: line color (separator between items), text color, active link color, and mobile menu background color.
Icons	color/size controls	Style the optional utility icons: Shopping Cart icon color and size, Search icon color and size, and Hamburger menu icon color and size. Each icon can be styled independently.
Logo	image styling	Configure styling for the logo image including border radius, border styles, box shadow, and image filters (brightness, contrast, saturation, etc.).

Shared design options — see Options Groups for detailed documentation:

Options Group	Description
Sizing	Width, max-width, height, min-height
Spacing	Margin and padding per side, responsive breakpoints
Border	Width, color, style, border radius
Box Shadow	Color, offsets, blur radius, spread
Filters	Brightness, contrast, saturation, hue, blur, invert, blend mode
Transform	Scale, translate, rotate, skew, transform origin
Animation	Entrance animation style, duration, delay, intensity

Advanced Tab

The Advanced tab provides developer-oriented controls for custom attributes, conditional display, and interaction behavior.

Shared advanced options — see Options Groups for detailed documentation:

Options Group	Description
Attributes	CSS ID, classes, custom HTML attributes
CSS	Custom CSS per element target (menu container, links, dropdowns, logo, icons)
HTML	Semantic HTML tag for the module wrapper (div, nav, header). Using nav is recommended for accessibility
Conditions	Display rules (user role, page type, date, logic)
Interactions	Hover, click, or scroll-triggered interactions
Visibility	Device visibility toggles
Transitions	Hover transition timing
Position	CSS position and offsets
Scroll Effects	Scroll-driven animation effects

Code Examples

Custom CSS

/* Style the Fullwidth Menu bar background and spacing */
.et_pb_fullwidth_menu {
    background-color: #1a1a2e;
    padding: 0 30px;
}

/* Style top-level menu links */
.et_pb_fullwidth_menu .et-menu a {
    color: #ffffff;
    font-size: 15px;
    font-weight: 500;
    padding: 20px 16px;
    transition: color 0.3s ease;
}

/* Hover state for menu links */
.et_pb_fullwidth_menu .et-menu a:hover {
    color: #e94560;
}

/* Style the dropdown sub-menus */
.et_pb_fullwidth_menu .et-menu .sub-menu {
    background-color: #16213e;
    border-top: 2px solid #e94560;
    min-width: 220px;
}

.et_pb_fullwidth_menu .et-menu .sub-menu a {
    color: #cccccc;
    font-size: 14px;
    padding: 12px 20px;
}

.et_pb_fullwidth_menu .et-menu .sub-menu a:hover {
    color: #ffffff;
    background-color: #0f3460;
}

/* Responsive adjustments */
@media (max-width: 980px) {
    .et_pb_fullwidth_menu {
        padding: 10px 15px;
    }
}

PHP Hooks

/* Filter the Fullwidth Menu module output */
add_filter('et_module_shortcode_output', function($output, $render_slug) {
    if ('et_pb_fullwidth_menu' !== $render_slug) {
        return $output;
    }
    // Example: Add a custom class based on the current page
    if (is_front_page()) {
        $output = str_replace(
            'et_pb_fullwidth_menu',
            'et_pb_fullwidth_menu home-menu',
            $output
        );
    }
    return $output;
}, 10, 2);

Common Patterns

1. Sticky Secondary Navigation — Place the Fullwidth Menu in a fullwidth section and set the Position to sticky with a top offset of 0 in the Advanced tab. Choose a solid background color and add a subtle box shadow so the menu bar floats above the content as visitors scroll, providing persistent access to key page sections.

2. Branded Header with Logo and Utility Icons — Select the Inline Centered Logo layout to place the logo between two groups of menu links. Enable both the Search and Shopping Cart elements for a complete e-commerce header. Style the menu text in white against a dark background and set the icon colors to match for a cohesive branded appearance.

3. Minimal Footer Navigation — Add a Fullwidth Menu near the bottom of the page with a centered layout, a simple WordPress menu containing legal and utility links, and no logo or icons. Use a smaller font size and muted text colors to create a clean, understated navigation bar that complements rather than competes with the primary footer content.

AI Interaction Notes

Create vs. Modify

Modifying existing module content via REST API (wp.apiFetch PATCH) updates title, body text, and settings attributes. Creating new modules via REST API produces content that renders on the front end but may not appear in the Visual Builder layer view. Use browser automation for reliable module creation. See REST API Content Playbook.

Block identifier: divi/fullwidth-menu — Needs verification on current build

Operation	Method	Status	Notes
Read content	Parse post_content block JSON	Observed	Use brace-depth parser — see Content Encoding
Modify existing	wp.apiFetch PATCH on post endpoint	Observed	Update block attributes in post_content
Create new	Browser automation (Playwright)	Observed	REST creation may break VB visibility
Batch modify	Sequential REST requests	Needs Testing	See REST API Content Playbook

Key content attributes — JSON paths need verification:

Attribute	JSON Path	Notes
Menu ID	attrs.menu_id	WordPress menu ID to display
Logo	attrs.logo	Logo image URL
Show Cart	attrs.show_cart_icon	WooCommerce cart icon toggle
Show Search	attrs.show_search_icon	Search icon toggle

Module Selection Guidance

For full-width navigation bars use Fullwidth Menu; for menus within content areas use Menu; for sidebar navigation use Sidebar.

Saving Your Work

After configuring the Fullwidth Menu:

• Save changes — Click the purple Save button at the bottom of the Visual Builder, or press Ctrl+S (Windows) / Cmd+S (Mac).
• Exit the builder — Click the X button or use Ctrl+Shift+E to return to the WordPress dashboard.

Version Notes

Divi 5 Only

This page documents Divi 5 behavior exclusively.

Troubleshooting

Menu Shows No Links

If the module appears but displays no navigation links, verify that you have selected a valid WordPress menu in the Content tab's Content dropdown. If no menus appear in the dropdown, go to Appearance > Menus in the WordPress admin and create a menu with at least one item before returning to the builder.

Shopping Cart Icon Not Appearing

The Shopping Cart toggle in the Elements settings requires WooCommerce to be installed and active. If WooCommerce is not detected, the cart icon will not display regardless of the toggle state. Verify that WooCommerce is installed, activated, and up to date.

Dropdown Menus Hidden Behind Other Content

If dropdown sub-menus appear behind other modules or sections on the page, the issue is typically a z-index conflict. Add a higher z-index value to the Fullwidth Menu module using the Position settings in the Advanced tab, or add custom CSS: .et_pb_fullwidth_menu { z-index: 999; }.

Related

• Menu — Standard-width version for use within regular sections and rows
• Sidebar — Widget-based navigation for sidebars and auxiliary content areas
