Fullwidth Map¶

The Fullwidth Map module displays an interactive Google Map that spans the entire width of a fullwidth section, with support for multiple location pins.

Quick Reference

What it does: Embeds a full-width interactive Google Map with customizable pins, info windows, and zoom controls. When to use it: Contact page location displays, multi-location directories, event venue showcases Key settings: Map center address, Zoom level, Pin titles/content/addresses, Mouse wheel zoom, Mobile dragging Block identifier: divi/fullwidth-map ET Docs: Official documentation

When to Use This Module

Displaying business locations on a contact page with edge-to-edge presentation
Showing multiple branch or franchise locations with individual info windows
Featuring event or venue locations prominently on landing pages

When NOT to Use This Module

For maps within content columns or standard sections → use Map
For static location display without interactivity → use an Image with a map screenshot
For non-Google map providers → use Code with a custom embed

Overview¶

The Fullwidth Map module embeds a Google Maps instance that stretches edge to edge within a fullwidth section. It provides visitors with an interactive map they can pan, zoom, and click to explore your business locations, event venues, or any geographic points of interest. Multiple pins can be added to mark different addresses, each with its own title and description that appear in an info window when clicked.

This module is functionally identical to the standard Map module but is designed exclusively for use within fullwidth sections. The edge-to-edge presentation makes it particularly effective on contact pages, location directories, and real estate listings where the map serves as a primary visual element rather than a secondary detail.

Before the module can display a map, you must configure a Google Maps API key in the Divi theme options. This requires creating a Google Cloud project, enabling the Maps JavaScript API, setting up billing, and generating an API key. Without a valid key, the module will show a placeholder or error message on the front end.

For additional reference, see the official Elegant Themes documentation for the Map module.

View A Live Demo Of This Module

The Fullwidth Map module displaying an interactive Google Map with location pins.

Use Cases¶

Contact Page Location Display — Embed a full-width map at the top or bottom of a contact page showing your office or store location, giving visitors an immediate visual reference and the ability to get directions with a single click.
Multi-Location Directory — Add multiple pins to showcase all branch offices, retail outlets, or franchise locations on a single map. Each pin can include the address, phone number, and hours in its info window description.
Event or Venue Showcase — Feature the location of an upcoming event, conference, or venue prominently on a landing page with a full-width map that visitors can interact with to explore nearby parking, hotels, and transit options.

How to Add the Fullwidth Map Module¶

Open the Visual Builder and ensure the page has a fullwidth section. If needed, click the blue + icon and select Fullwidth as the section type.
Click the gray + icon inside the fullwidth section to open the module picker.
Search for "Fullwidth Map" or browse the Fullwidth Modules category, then click to insert it into the section.

Settings & Options¶

The Fullwidth Map module settings are organized across three tabs: Content, Design, and Advanced.

Content Tab¶

The Content tab controls the map's location, pins, link behavior, and background.

Setting	Type	Description
Add New Pin	item list	Add, edit, and remove map pins. Each pin has its own address, title, and content fields. Click + to add a pin, the pencil icon to edit, the trash icon to delete, and drag to reorder.
Map	location selector	Set the geographic center point and default zoom level for the map. Enter an address or coordinates to position the initial view. Requires a valid Google Maps API key configured in theme options.
Link	url	Make the entire module clickable, redirecting users to another page, section, or external URL when they click outside of map controls.
Background	background controls	Set a background color, gradient, image, or video behind the module. This is visible if the map has any transparent areas or during loading.
Loop	toggle	Enable the Loop Builder to dynamically generate map content from posts or custom post types.
Order	select	Control the display order of the module when placed inside a Flexbox or CSS Grid layout container.
Meta	admin label	Set a custom label to identify the module in the Visual Builder's layer panel. Includes a toggle to force visibility in the builder.

Individual Pin Settings¶

Each map pin has its own configuration when you click to edit it:

Setting	Type	Description
Title	text	The heading displayed in the pin's info window when a visitor clicks the marker.
Content	rich text editor	The body text shown in the info window below the title. Supports HTML for formatting addresses, phone numbers, and links.
Address	text / geocoder	The physical address or coordinates used to place the pin on the map. The address is geocoded through the Google Maps API.

Design Tab¶

The Design tab controls the map's interactive behavior, visual filters, and dimensional styling.

Module-specific settings:

Setting	Type	Description
Controls	toggle options	Enable or disable map interaction controls. Options include mouse wheel zoom (prevents accidental zooming while scrolling) and mobile dragging (prevents the map from capturing touch gestures on mobile devices).
Map	filter options	Apply visual filters to the map tiles themselves, allowing you to adjust the map's color scheme to better match your site's design without using a custom map style.

Shared design options — see Options Groups for detailed documentation:

Options Group	Description
Sizing	Width, max-width, height, min-height
Spacing	Margin and padding per side, responsive breakpoints
Border	Width, color, style, border radius
Box Shadow	Color, offsets, blur radius, spread
Filters	Brightness, contrast, saturation, hue, blur, invert, blend mode
Transform	Scale, translate, rotate, skew, transform origin
Animation	Entrance animation style, duration, delay, intensity

Advanced Tab¶

The Advanced tab provides developer-oriented controls for custom attributes, conditional display, and interaction behavior.

Shared advanced options — see Options Groups for detailed documentation:

Options Group	Description
Attributes	CSS ID, classes, custom HTML attributes
CSS	Custom CSS per element target (map container, pin markers, info windows)
HTML	Semantic HTML tag for the module wrapper (div, section, aside)
Conditions	Display rules (user role, page type, date, logic)
Interactions	Hover, click, or scroll-triggered interactions
Visibility	Device visibility toggles
Transitions	Hover transition timing
Position	CSS position and offsets
Scroll Effects	Scroll-driven animation effects

Code Examples¶

Custom CSS¶

/* Adjust the Fullwidth Map height for a more prominent display */
.et_pb_fullwidth_map {
    min-height: 500px;
}

/* Style the map info window content */
.et_pb_fullwidth_map .gm-style-iw {
    max-width: 300px;
    padding: 10px;
}

/* Style the info window title */
.et_pb_fullwidth_map .gm-style-iw h4 {
    font-size: 16px;
    font-weight: 600;
    margin-bottom: 8px;
}

/* Add a subtle border above the map for visual separation */
.et_pb_fullwidth_map {
    border-top: 3px solid #2ea3f2;
}

/* Responsive height adjustments */
@media (max-width: 980px) {
    .et_pb_fullwidth_map {
        min-height: 350px;
    }
}

@media (max-width: 767px) {
    .et_pb_fullwidth_map {
        min-height: 250px;
    }
}

PHP Hooks¶

/* Filter the Fullwidth Map module output */
add_filter('et_module_shortcode_output', function($output, $render_slug) {
    if ('et_pb_fullwidth_map' !== $render_slug) {
        return $output;
    }
    // Example: Wrap the map in a container for additional styling control
    $output = '<div class="custom-map-wrapper">' . $output . '</div>';
    return $output;
}, 10, 2);

Common Patterns¶

Contact Page Footer Map — Place the Fullwidth Map module as the last element on a contact page, directly above the site footer. Add a single pin for your primary location with the full address, phone number, and business hours in the pin content. Disable mouse wheel zoom to prevent accidental map interactions while visitors scroll.
Multi-Location with Desaturated Style — Add pins for all business locations and use the Design tab's Map Filters to desaturate the map tiles, creating a grayscale base that matches a minimalist site design. The colored pin markers stand out clearly against the muted background, drawing attention to each location.
Sticky Map Section — Use the Advanced tab's Position settings to make the fullwidth section containing the map sticky, so it remains visible while visitors scroll through a list of location details in adjacent sections. This creates a split-view experience where the map updates context as users read about each location.

AI Interaction Notes¶

Create vs. Modify

Modifying existing module content via REST API (wp.apiFetch PATCH) updates title, body text, and settings attributes. Creating new modules via REST API produces content that renders on the front end but may not appear in the Visual Builder layer view. Use browser automation for reliable module creation. See REST API Content Playbook.

Block identifier: divi/fullwidth-map — Needs verification on current build

Operation	Method	Status	Notes
Read content	Parse `post_content` block JSON	Observed	Use brace-depth parser — see Content Encoding
Modify existing	`wp.apiFetch` PATCH on post endpoint	Observed	Update block attributes in `post_content`
Create new	Browser automation (Playwright)	Observed	REST creation may break VB visibility
Batch modify	Sequential REST requests	Needs Testing	See REST API Content Playbook

Key content attributes — JSON paths need verification:

Attribute	JSON Path	Notes
Address	`attrs.address`	Map center address or coordinates
Zoom	`attrs.zoom_level`	Default map zoom level
Mouse Wheel	`attrs.mouse_wheel`	Toggle mouse wheel zoom behavior

Module Selection Guidance

For edge-to-edge maps use Fullwidth Map; for maps within content columns use Map.

Saving Your Work¶

After configuring the Fullwidth Map:

Save changes — Click the purple Save button at the bottom of the Visual Builder, or press Ctrl+S (Windows) / Cmd+S (Mac).
Exit the builder — Click the X button or use Ctrl+Shift+E to return to the WordPress dashboard.

Version Notes¶

Divi 5 Only

This page documents Divi 5 behavior exclusively.

Troubleshooting¶

Map Shows Gray Area or Error Message

If the map displays a gray placeholder, a "For development purposes only" watermark, or an API error, your Google Maps API key is either missing, invalid, or has billing issues. Go to Divi > Theme Options > General and verify the API key. Ensure billing is enabled on your Google Cloud project and the Maps JavaScript API is activated.

Pins Not Appearing at Correct Locations

If pins are placed in the wrong position or not showing at all, verify that the addresses entered in each pin's settings are complete and correctly formatted. Ambiguous addresses (like just a city name) may geocode to unexpected locations. Use full street addresses or latitude/longitude coordinates for precision.

Map Interferes with Page Scrolling on Mobile

On mobile devices, visitors may accidentally interact with the map when trying to scroll the page. Enable the "Disable Mobile Dragging" option in the Design tab's Controls settings to prevent the map from capturing touch scroll gestures, allowing visitors to scroll past the map normally.

Map — Standard-width version for use within regular sections and rows
